Network FM200(HFC-227ea) Fire Extinguishing System

FM200 (Heptafluoropropane, HFC-227ea) automatic fire extinguishing system is a gas fire, automatic control and fire detection is one of the modern intelligent automatic fire extinguishing system.

• Features:
  1. The fire extinguishing speed, high efficiency, strong initiative.
  FM200 clean gas automatic fire extinguishing system can completely extinguish fire in 10 seconds, usually clean gas fire extinguishing agent FM – 200 relative to the reserve design fire extinguishing concentration is low, only 9%, FM – 200 clean fire extinguishing agent is liquid is stored and can be quickly purification clean fire extinguishing gas, highly motivated to put out a fire.
  2. ​Clean
  FM200 clean gas automatic fire extinguishing system is very suitable for protection of electrical, magnetic media, documents, or high value of collection and equipment, and the protected objects without damage, without leaving any residue after fire, do not interrupt the daily work of protected areas.
  3. The security
  FM200 clean fire extinguishing gas is internationally recognized as harmless to the human body of fire extinguishing agent, non-toxic and will not cause respiratory problems.FM – 200 clean gas automatic fire extinguishing system to release pressure of small, non-toxic, very suitable for resident staff reserves.
  4. Environmental
  FM200 clean fire extinguishing gas is not international environmental groups included in the stop the use of gas, will not damage the atmospheric ozone layer, the remaining period in atmosphere is only 31 ~ 42 years.
  5. Economic
  FM200 clean gas automatic fire extinguishing system for the current environmental protection laws and regulations, so without replacement and duplication of investment in the future.Can also be used in design of the combined distribution method design centralized storage systems, more economic efficient fire protection.FM – 200 clean gas automatic fire extinguishing system is small in size, number of cylinders is little, so can save the area between the gas cylinder or don’t need a cylinder.
  6. Mature
  FM200 clean gas is to use made in the United States dupont chemical company of technology of synthesis, around the world has tens of thousands of cases of successful application, have been excessive ten years of practice test.On the international supporting design and engineering specifications.

• Parameters:


  Filling pressure	4.2 MPa	Extinguishing agent release time	≤10s
  Extinguishing agent filling density	≤950kg/m3	valve drive air pressure	6.0±1.0 MPa(20℃)
  System Power Supply	AC220V/DC24V/1A	System working environment temperature	-10℃～55℃
  System protection limits area	The largest single area 800m²; volume : the largest single area 3600m ³
  System start-up mode	Automatic system startup, electrical manual, mechanical emergency manual.
  Storage bottle volume	70L,90L,120L,150L,180L

  Drawing:
